Plug Valves

High-performance Plug Valves designed for dependable shut-off, flow control and long service life in demanding industrial applications.

Plug Valve

Plug Valves

Full Bore, Regular Bore & Extended Stem

Our Plug Valves are engineered for reliable isolation, positive shut-off and dependable performance across demanding industrial and process applications. They are available in multiple materials, pressure classes, end connections and actuator configurations.

↔
½" - 36" Size Range
◉
150# - 2500# Pressure
✓
API / ASME Standards
⚙
3 Types Versions
▣ Request a Quote ↓ Download Brochure
Technical Data
01

Size & Pressure Rating

Size ½" up to 36" (DN 15 up to DN 900)
Pressure Rating ASME 150# to 2500#
Pressure / Temperature Rating ASME B 16.34
02

Available Materials

Carbon Steels Low Temperature Carbon Steel Martensitic Steels Austenitic Stainless Steel Duplex Stainless Steels Super Duplex Stainless Steels Nickel Alloys Nickel Aluminum Bronze Hastelloy Inconel Titanium Alloy Carbon Steel with Internal Corrosion Resistant Alloy (CRA) Overlay
03

Design & Inspection Standards

Design Standard

API 6D API 599 BS 5353 MESC SPE 77/107

Pressure / Temperature Rating

ASME B 16.34

Test (Inspection) Standard

API 598 API 6D MESC 77/107 ISO 5208
04

Construction Details

Inverted Plug Pressure Balanced Lubricated
05

End Connection & Operator / Actuator

End Connection

Screwed Socket Weld Flanged Hub End Butt-Weld

Operator / Actuator

Lever Gear Pneumatic Hydraulic Electro-Hydraulic Electric Motorised
06

Plug Valve Types

Plug Valves are available in three different types:

01
Full Bore
02
Regular Bore
03
Extended Stem Valves

Reliable Plug Valve Solutions

Our Plug Valves are available in Full Bore, Regular Bore and Extended Stem configurations for reliable isolation and flow control across a wide range of industrial applications.
